USB camera splitter ! Turn one UVC webcam into two output

Shipping package:

1. usb camera splitter x1

2. USB-C CABLE X 3

USB WEBCAM splitter adapter can connect a UVC webcam and turn it be two output.

1. Please put this adapter under environment temperature is below 30 °C ( < 86℉ )

   this adapter is ultra smallest.  so, it will be hot.

2.  USB WEBCAM compatitble list

   not all of usb webcam can work on this adapter.

   so far I test some usb webcam as below list

Product outlook ：

1. PCBA module

2. With metal case:

   due to the hot issue, I add its volume.

   35mm x 65mm x95mm

How to use?

Product spec ：

1. USB WEBCAM INPUT  format :

    1. 1 UVC1.1 ~UVC1.5 version

     1.2 your usb webcam need be compatitble for USB2.0 mode

     1.3 accept MJPG or YUV

     1.4 for safety, please follow my usb webcam compartible test table

2. uvc input resolution is up to 1920x1080p 30fps mjpg , 1920x1080p  yuv

3. two way uvc output resolution is up to 1920x1080p 30fps mjpg

   ( uvc resloution is 320x240, 640x420, 1280x720....1920x1080p 30fps mjpg)

3. USB webcam input resolution is independce of output uvc webcam resolution

  eg:   if usb webcam input resolution is 640x480,  it also can be output 1920x1080p

4. usb camera adapter power issue:

   4.1 without usb webcam input power, it is about 500 mA ~650mA @ 5V

   4.2 you need add a usb webcam power consumption

   4.3 Total power consumption is  as below

      power of adapter + power of usb webcam

Application:

1.atem mini  (pro)

  1.1 dual live streaming on OBS

1.2  create a PGM monitor with android phone

2. USB WEBCAM

  2.1 dual live streaming on OBS

2.2 androoid phone as a monitor
